flag hinges

Flag Hinges

Hinges are available in steel, aluminum, and stainless steel.

Custom Metal Stamping

Flag hinges are made for "take-apart" applications. Flag Hinges can also swivel a full 360° around the pin. Flag hinges are manufactured with either a right-hand or left-hand configuration. Velko can manufacture custom flag hinges in a wide variety of lengths, metals, and finishes, all to a customer's drawing or specifications. Please contact Velko or send us your prints or drawings for a quote.

Show All Swaging Options Swaging Options

Please note: Minimum orders are $300.00.

Flag Hinges
Available in steel, aluminum, and stainless steel
Show Diagram of Hinge Dimensions Hinge and Pin Anatomy
Item # Decimal Thickness(T) Pin Diameter(P) Open Width(OW) Length(L)
FL918-1 0.09 in
2.3 mm		 0.188 in
4.8 mm		 3 in
76.2 mm		 3 in
76.2 mm
FL918-2 0.09 in
2.3 mm		 0.188 in
4.8 mm		 3.5 in
89 mm		 3.5 in
89 mm
FL925-1 0.09 in
2.3 mm		 0.25 in
6.35 mm		 3.5 in
89 mm		 3.5 in
89 mm
FL925-2 0.09 in
2.3 mm		 0.25 in
6.35 mm		 4 in
101.6 mm		 4 in
101.6 mm
FL1225-1 0.12 in
3 mm		 0.25 in
6.35 mm		 3.5 in
89 mm		 4 in
101.6 mm
FL1225-2 0.12 in
3 mm		 0.25 in
6.35 mm		 4 in
101.6 mm		 4 in
101.6 mm
FL1231 0.12 in
3 mm		 0.312 in
8 mm		 4 in
101.6 mm		 4 in
101.6 mm
FL1837-1 0.18 in
4.5 mm		 0.375 in
9.5 mm		 4 in
101.6 mm		 4 in
101.6 mm
FL1837-2 0.18 in
4.5 mm		 0.375 in
9.5 mm		 4 in
101.6 mm		 5 in
127 mm

More Information

Please provide Velko Hinge with your prints, drawings, or sketches along with specifications and dimensions.
