military hinges

Military Hinges

Hinges are available in steel, aluminum, and stainless steel.

Custom Metal Stamping

Military hinges, also referred to as continuous hinges, are long hinges that run the entire length of a door, panel, box or other item. Military hinges are manufactured either with or without holes. These hinges also come in various thicknesses, pin diameters, and knuckle lengths. Military hinges can be used in any setting requiring a hinge of a specific length.

Velko can manufacture custom military hinges for a wide variety of purposes. Common military hinge types include the following:

Military Hinges - Series MS35000 Continuous Hinges
Available in steel, aluminum, and stainless steel
Show Diagram of Hinge Dimensions Hinge and Pin Anatomy
Item # Leaf Thickness(T) Knuckle(KL) Pin Diameter Length(L)
MS35822 0.04 in 0.5 in
0.62 in
0.091 in 72 in
72.50 in
MS35823 0.05 in 0.62 in 0.125 in 72.5 in
MS35825 0.06 in 0.62 in
1 in
0.125 in 84 in
85 in
MS35826 0.06 in 1 in
2 in
0.187 in 84 in
MS35829 0.075 in 2 in 0.187 in
0.250 in
84 in
MS35830 0.09 in 2 in 0.250 in
0.312 in
0.375 in
84 in
MS35831 0.125 in 2 in 0.312 in
0.375 in
84 in
Military Hinges - Series AA55000 Continuous Hinges
Available in steel, aluminum, and stainless steel
Show Diagram of Hinge Dimensions Hinge and Pin Anatomy
Item # Leaf Thickness(T) Knuckle(KL) Pin Diameter Length(L)
AA55590 0.04 in 0.5 in
0.62 in
0.091 in 72 in
72.50 in
AA55591 0.05 in 0.62 in 0.125 in 72.5 in
AA55592 0.06 in 0.62 in
1 in
0.125 in 84 in
85 in
AA55593 0.06 in 1 in
2 in
0.187 in 84 in
AA55594 0.075 in 2 in 0.187 in
0.250 in
84 in
AA55595 0.09 in 2 in 0.250 in
0.312 in
0.375 in
84 in
AA55596 0.125 in 2 in 0.312 in
0.375 in
84 in

More Information

Please provide Velko Hinge with your prints, drawings, or sketches along with specifications and dimensions.

Contact Us

manufacture continuous, butt, slip joint, flag and military hinges

We manufacture continuous, butt, slip joint, flag, and military hinges.
